High Speed Compact And Flexible CNC AC Servo Motor Drive With 24 Bit Absolute Encoder

CNC AC Servo Motor Drive
Power 7.5KW
Three Phase 380V
Modbus / CanOpen / EtherCAT
Location, Speed and Torque Control Mode
24 bit absolute encoder;

Products Description

Installation Precautions

● When installing, do not block the suction and exhaust ports, and do not allow foreign objects

inside the product to enter,otherwise it may cause malfunction or fire due to aging of internal components.
● Do not place heavy objects on or under this product as this may result in injury.
● Please install in the following environment:
1.places without direct sunlight;
2.Locations where the ambient temperature is in the range of 0 ° C to 55 ° C;
3.Relative humidity in the range of 0% to 95%, and no condensation;
4.Locations free of water droplets, vapors, dust and oily dust;
5.Locations where there is no high heat device;
6.Non-corrosive, flammable gas and liquid sites;
7.It is not easy to splash water, oil and medicine;
8.places that are not exposed to radioactive radiation;
9.Strong and vibration-free places;
10.Locations where there is no electromagnetic noise interference.

The panel contains 5 buttons and 5 digital tubes.
The general functions of the five buttons are shown in the table below.

Accessories:

	Accessory name	Image
Satandard Spare Parts	Power terminal		Adapt to E1,E2 structure drive
	Cn3 encoder plug		Encoder plug on the driver side
	Cn4 control terminal plug		Input/output signal terminals,user wiring
	Encoder connection line		The standard cable length is 3, 5, 8, 10, 13, 15 meters, according to customer needs Provide independent connector
	Power line		The standard cable length is 3, 5, 8, 10, 13, 15 meters, according to customer needs Provide independent connector
	Drive monitoring line		Connect and adjust the software for remote monitoring and firmware update
Purchasing Spare Parts	USB to RS232 Adapter cable		If necessary, self purchase
	Ethernet communication line		If necessary, self purchase

Other Questions:
Q1. How to select the suitable model?
A: Please confirm your requirements for Rated Power, Current, Voltage,
Torque and select the suitable model based our model list;
Q2. How to set the programming system?
A: Our Servo drive support the Global Communication protocols: Modbus/CANopen/EtherCAT,
Please Just make the programming follow your experiences;
Q3. What's the power range about our servo system?
A: Our Power range covers 0.2-110KW, reach your requirements;
Q4. What's the encoder feedback interfaces we using?
A: We have multiple Encoder feedback interfaces, like : incremental/wire-saving encoder,
17-bit/23-bit/24-bit absolute encoder, resolver encoder, etc.
